Lincoln K2400-1 Idealarc CV350 MIG Welder
$ 6,387.00
Lincoln K2400-1 Idealarc CV350 MIG Welder
You won't find a more reliable power source.
This unit is the most compact unit in its class, yet it's loaded with convenient features! A digital meter, line voltage compensation and remote/local control are all standard.
Input Power:
- 208/230/260/3/60
Processes:
- MIG, Flux Cored
TWO OUTPUT CONNECTORS
- Allow you to connect to high or low inductance for optimal arc control
- Use low inductance output connection when short-arc welding, and high inductance output connection with spray and globular transfer welding
DIGITAL AMMETER/VOLTMETER
- Display allows presets for added convenience and accuracy
EASY ACCESS TWIST MATE® CONNECTION
- On the front of the machine
QUALITY & RELIABILITY
- Environmentally protected transformer and power rectifier are rugged and reliable
SEVEN YEAR WARRANTY ON THE POWER RECTIFIER
| INPUT POWER | 208/230/460/3/60 |
| RATED OUTPUT | 315A/32.6V/100% |
| INPUT CURRENT | 51/48/24A |
| OUTPUT RANGE | 50-400A DC 7-37V |
| DIMENSIONS (H X W X D) | 24.6" x 19.5" x 27" (625 x 495 x 686 mm) |
| NET WEIGHT | 300 lb (136.08 kg) |
| CATEGORY | PRODUCT NUMBER | PRODUCT NAME |
| General | K1803-1 | Lincoln Weld Cable Package |
| General | K867 | Lincoln Universal Adapter Plug |
| General | K857 | Lincoln Remote Output Control - 25 ft |
| General | K857-1 | Lincoln Remote Output Control - 100 ft |
| General | K864 | Lincoln Remote Control Adapter |
| General | K852-70 | Lincoln Twist Mate Plug for 1/0-2/0 Cable |
| General | K852-95 | Lincoln Twist Mate Plug for 2/0-2/0 Cable |
| General | K484 | Lincoln Jumper Plug Kit |
| General | K874 | Lincoln Undercarriage |
| PRODUCT NUMBER | PRODUCT NAME |
| K2327-4 | Lincoln LF-72 Wire Feeder, Base Model |
| K2327-5 | Lincoln LF-72 Wire Feeder, Bench Model, Standard Duty |
| K2327-6 | Lincoln LF-72 Wire Feeder, Bench Model, Heavy Duty |
| K2327-7 | Lincoln LF-72 Wire Feeder, Bench Model, Heavy Duty |
| K2426-5 | Lincoln LF-74 Wire Feeder, Bench Model, Heavy Duty |
| K2426-4 | Lincoln LF-74 Wire Feeder, Base Model |
