Lincoln K2400-1 Idealarc CV350 MIG Welder

$ 6,387.00
By Lincoln Electric

Lincoln K2400-1 Idealarc CV350 MIG Welder





You won't find a more reliable power source.



This unit is the most compact unit in its class, yet it's loaded with convenient features! A digital meter, line voltage compensation and remote/local control are all standard.



Input Power:

  • 208/230/260/3/60



Processes:

  • MIG, Flux Cored



Features & Benefits



TWO OUTPUT CONNECTORS

  • Allow you to connect to high or low inductance for optimal arc control
  • Use low inductance output connection when short-arc welding, and high inductance output connection with spray and globular transfer welding



DIGITAL AMMETER/VOLTMETER

  • Display allows presets for added convenience and accuracy



EASY ACCESS TWIST MATE® CONNECTION

  • On the front of the machine



QUALITY & RELIABILITY

  • Environmentally protected transformer and power rectifier are rugged and reliable



SEVEN YEAR WARRANTY ON THE POWER RECTIFIER



Specifications



INPUT POWER 208/230/460/3/60
RATED OUTPUT 315A/32.6V/100%
INPUT CURRENT 51/48/24A
OUTPUT RANGE 50-400A DC
7-37V
DIMENSIONS (H X W X D) 24.6" x 19.5" x 27" (625 x 495 x 686 mm)
NET WEIGHT 300 lb (136.08 kg)



Accessories



CATEGORY PRODUCT NUMBER PRODUCT NAME
General K1803-1 Lincoln Weld Cable Package
General K867 Lincoln Universal Adapter Plug
General K857 Lincoln Remote Output Control - 25 ft
General K857-1 Lincoln Remote Output Control - 100 ft
General K864 Lincoln Remote Control Adapter
General K852-70 Lincoln Twist Mate Plug for 1/0-2/0 Cable
General K852-95 Lincoln Twist Mate Plug for 2/0-2/0 Cable
General K484 Lincoln Jumper Plug Kit
General K874 Lincoln Undercarriage



Wire Feeders



PRODUCT NUMBER PRODUCT NAME
K2327-4 Lincoln LF-72 Wire Feeder, Base Model
K2327-5 Lincoln LF-72 Wire Feeder, Bench Model, Standard Duty
K2327-6 Lincoln LF-72 Wire Feeder, Bench Model, Heavy Duty
K2327-7 Lincoln LF-72 Wire Feeder, Bench Model, Heavy Duty
K2426-5 Lincoln LF-74 Wire Feeder, Bench Model, Heavy Duty
K2426-4 Lincoln LF-74 Wire Feeder, Base Model
