LINCOLN Fleetweld® 47 ED038100 E7014 3/16 x 14 IN 10CPL (40CT)
$ 215.00
Unit price
/
Unavailable
Couldn't load pickup availability
Fleetweld® 47
Stick (SMAW) | ED038100
CLASSIFICATIONS:
E7014
Mild Steel, Rutile • AWS E7014
DETAILS
Specifically designed for vertical down welding of sheet metal and ornamental iron
Features
- Good restrike characteristics
- Smooth and transfer and good wetting and low penetration
- Operates on low amperages
- High deposition rates
- Excellent operator appeal
MECHANICAL PROPERTIES
| Classification |
|---|
| E7014 Requirement |
| Typical Result, As-welded |
|
Yield Strength @ 0.2% Offset MPa (ksi) |
Tensile Strength MPa (ksi) |
Elongation % |
Charpy V-Notch J (ft-lbs) @ -30°C (-20°F) |
|---|---|---|---|
| 400 (58) min. | 480 (70) min. | 17 min. | |
| 410-470 (60-69) | 490-540 (71-78) | 18-29 | 27-83 (20-61) |
CONFORMANCE
| CONFORMANCES |
|---|
| AWS |
| ABS |
| BV |
| CWB |
| DNV-GL |
| LR |
| SPECIFICATION | CLASSIFICATION |
|---|---|
| AWS A5.1 | E7014 |
| AWS A5.1 | E7014 |
| BV - Chapter 5 | 1 |
| CSA W48 | E4914 |
| DNV - 2.9 | 1 |
| LR - Chapter 11 | 1M |
