Lincoln K471-21 Magnum® 400 Welding Gun Package, .035" - .045" Liner, 15 ft
$ 625.00
$ 657.00
Unit price
/
Unavailable
Couldn't load pickup availability
Lincoln K471-21 Magnum® 400 Welding Gun Package, .035" - .045" Liner, 15 ft
SEMIAUTOMATIC GAS-SHEILDED GUNS
Magnum® guns for MIG or flux-cored welding feature our classic curved handle and are available in a number of amperage ranges for use in many applications.
Processes
- MIG, Flux-Cored Gas-Shielded
Wire Diameter Range
- .025" - 5/64" (0.6 - 2.0 mm)
Features and Benefits
BUILT FOR OPERATOR COMFORT
- When welding with the greater heat levels generated by higher amperage applications for most .045" - 1/16" (1.2 - 1.6 mm) gas-shielded operations
ONE-PIECE MODULAR TRIGGER ASSEMBLY
- Molded out of high heat resistant material to withstand head and spatter and ensure long life
GUN TUBE DESIGN
- Armored with an electrically insulated metal jacket optimizing fine wire welding performance
ABRASION-RESISTANT, EXTRUDED RUBBER JACKET
- Adds strength and long life to the cable
CLASSIC CURVED HANDLE
- Lightweight and balance, providing a comfortable grip to reduce fatigue
ROTATING GUN TUBE AND GUN HANGER CLIP
- Allow any number of hand positions to reduce fatigue or fit into tight spaces
Specifications
| DUTY CYCLE AT RATED AMPERAGE | 60% |
| RATED AMPERAGE | 400 |
| GUN TYPE | Handheld |
| CABLE LENGTH | 15 ft |
| WIRE DIAMETER | .025" - 5/64" (0.6 - 2.0 mm) |
| COOLING | Air Cooled |
| NET WEIGHT | 11.78 lbs (5.34 kg) |
Included
- Contact Tip
- Gas Diffuser
- Gas Nozzle
- Insulator
- Cable Liner
- Gun Tube (60°)
- Gun Connector (K466-1)
Accessories
| CATEGORY | PRODUCT NUMBER | PRODUCT NAME |
| General | K466-1 | Lincoln LN-7-8-9 & LN-25 Series Connector Kit |
| General | K466-10 | Lincoln LF-72-74, LN-25 Pro, Power Feed 25M Connector Kit |
| General | K466-6 | Lincoln Power MIG & Power Wave C300 Gun Connector Kit |
Contact Tips
| PRODUCT NUMBER | PRODUCT NAME |
| KP14-30 | Lincoln .030" Contact Tip |
| KP14-35 | Lincoln .035" Contact Tip |
| KP14H-35 | Lincoln .035" Heavy Duty Contact Tip |
| KP14-45 | Lincoln .045" Contact Tip |
| KP14H-45 | Lincoln .045" Heavy Duty Contact Tip |
| KP14A-364 | Lincoln 3/64" Contact Tip |
| KP14AH-364 | Lincoln 3/64"A Heavy Duty Contact Tip |
| KP14-116 | Lincoln 1/16" Contact Tip |
| KP14H-116 | Lincoln 1/16"A Heavy Duty Contact Tip |
Nozzles
| PRODUCT NUMBER | PRODUCT NAME |
| KP24A-62 | Lincoln .62" Adjustable Slip-On Gas Nozzle |
| KP23-50F | Lincoln .50" Flush Gas Nozzle |
| KP23-62 | Lincoln .62" Fixed Recessed Gas Nozzle |
| KP23-62F | Lincoln .62" Fixed Flush Gas Nozzle |
| KP23H-62 | Lincoln .62" Fixed Heavy Duty Gas Nozzle |
Diffusers
| PRODUCT NUMBER | PRODUCT NAME |
| KP54A | Lincoln .025" - 5/64" Gas Diffuser for Magnum Gun |
Insulators
| PRODUCT NUMBER | PRODUCT NAME |
| KP34A | Lincoln Insulator for Adjustable Slip Nozzle |
Liners
| PRODUCT NUMBER | PRODUCT NAME |
| KP44-116-15 | Lincoln .052" - 1/16" Cable Liner (15 ft) |
| KP44-116-25 | Lincoln .052" - 1/16" Cable Liner (25 ft) |
| KP44-3545-15 | Lincoln .035" - .045" Cable Liner (15 ft) |
| KP44-3545-25 | Lincoln .035" - .045" Cable Liner (25 ft) |
| KP44N-3545-15 | Lincoln .035" - 3/64" Aluminum Cable Liner (15 ft) |
Gun Tubes
| PRODUCT NUMBER | PRODUCT NAME |
| KP1928-1 | Lincoln 60° 400 Amp Magnum Gun Tube Assembly |
| KP1929-1 | Lincoln 45° 400 Amp Magnum Gun Tube Assembly |
